LS-24N-D Server

中央處理器	Intel® Xeon® E3-1200 v3 series, Core i7/i5/i3 (non-ECC UDIMMs only), Pentium® & Celeron® processorsSocket H2 (LGA 1155)A Graphic Integrated CPU is required to have the on-board video functioned. For example: E3-1245, E3-1275
記憶體	4x DDR3 DIMM sockets, 1600/1333MHzSupports up to 32 GB DDR3 ECC and non-ECC UDIMM
陣列卡*	SAS 6Gb Hardware RAID 512MB of DDR2 667MHz cache memory
擴充槽*	2x PCI-E 3.0 x8 in x16 slot2x PCI-E 2.0 x4 (1 in x8)2x PCI-E 2.0 x1 & 1x PCI-32bit 5V slots
硬碟插槽	24* Hot-swap 3.5″ “HDD Bays
附屬儲存	No Device Options: 1 * Slim光碟機
網路功能	Dual LAN via Intel® 82579LM + 82574L Gigabit EthernetSupports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
產品尺寸	mm: 483 x 679 x 173.5inches: 19 x 26.7 x 7
電源規格	1010W 1+1 hot-swap redundant

*請參考選購項目

作業系統(選購)

Microsoft® Windows 7 x32/x64
Microsoft® Windows Storage Server 2008 R2 x64
Microsoft® Windows Storage Server 2012 R2 x64
Microsoft® Windows Server 2008 R2 x64
Microsoft® Windows Server 2012 R2 x64

Linux (Kernel 2.6 or later)
